Manganese brass foil is a complex brass with manganese as the main additive element. The role of manganese in reducing the a-zone of copper-zinc alloy is very small, and it has little effect on the microstructure of brass. Manganese plays a solid solution strengthening role in manganese brass foil, which can improve its strength and hardness. Manganese brass foil has high corrosion resistance and excellent casting properties. |
Item |
Manganese Brass Foil |
Standard |
ASTM, AISI, JIS, ISO, EN, BS, GB, etc. |
Shape |
Roll |
Size |
Width: 0.4mm~40mm Thickness: 0.03mm~2.9mm Various sizes can be customized |
Surface |
Bright |
Export to |
United States, Australia, Brazil, Canada, Germany, Peru, Japan, Italy, United Kingdom, Arabia, etc. |
Transport package |
Packed with waterproof paper or woven bag, packed in pallet or wooden box. Packaging can be customized according to customer requirements. |
Price term |
EXW, FOB, CIF, CFR, CNF, etc. |
Payment |
T/T, Western Union, L/C, etc. |
Certificates |
TUV&ISO&GL&BV,etc. |
Tensile strength σb (MPa) |
≥490 |
Elongation δ10 (%) |
≥15 |
Uniform corrosion properties |
From the SEM morphology of the surface of manganese brass after uniform corrosion in 3.5% NaCl solution, it can be seen that both zirconium microalloyed and unalloyed manganese brass are corroded and have some pits. The difference is that the surface of the unalloyed manganese brass has a block-like structure with obvious protruding surface and relatively more and larger pits. |
HMn62-3-3-0.7 chemical composition
Copper (Cu) |
Tin (Sn) |
Zinc (Zn) |
Lead (Pb) |
Phosphorus (P) |
Aluminum (Al) |
Iron (Fe) |
Manganese (Mn) |
Antimony (Sb) |
Note |
53.0 ~ 58.0 |
≤0.2 |
balance |
≤0.5 |
≤0.02 |
≤0.3 |
0.5 ~ 1.5 |
3.0 ~ 4.0 |
≤0.05 |
≤1.5 (impurities) |
FAQ: Q1: About product prices? A: The price is based on your quantity, if the quantity is large, the price is more reasonable. Q2: Can we supply the sample ? A: Yes,we can supply the sample.You can tell us the detail size. Q3: What are we? A: We are factory sales and can supply goods at very favorable prices. |
