Standard

ASTM, AISI, JIS, ISO, EN, BS, GB, etc.

Material

pure nickel and nickel alloy

Size

Wire: 0.030mm~10mm

Ribbon: 0.05*0.2mm~2.0*6.0mm

Strip: 0.5*5.0mm~5.0*250mm

According to customers requirement

Ni (Min)

99%

Application

1. Widely used in electronic products, is the first choice for making resistance element material
2. Pure nickel wire as electric vacuum material has good processing performance, strong welding(fusion welding, brazing welding),can be used for electroplating .
3. And can be used to produce such as corrosion resistance strong electron tube, bulbs, fluorescent lamp, anode, spacers, electrode holder, lighting, radio equipment, weaving nets, chemical, petroleum, power, aviation, Marine development and environmental protection, etc.

Elongation (≥ %)

15~25

Export to

United States, Australia, Brazil, Canada, Germany, Peru, Japan, Italy, United Kingdom, Arabia, etc.

Package

1. Finished products should be wrapped by brown paper & plastic warp then put in carton
2. Silver-coated soft cooper wire should be wound on reel. Ther should be some distance between product surface and the edge of reel.

Price term

EXW, FOB, CIF, CFR, CNF, etc.

Payment

Certificates

Ultimate Strength (≥ MPa)

690

Features

1. With weldability, high electrical conductivity, suitable linear expansion coefficient

2. Good strength at high temperature, low resistivity

3. High melting point, corrosion resistance, good mechanical properties, in hot and cold state have good pressure workability, easy to degassing, suitable for radio, electric light source, mechanical manufacturing, chemical industry, is an important structural material in vacuum electronic devices.

Characteristics of pure nickel wire:

Nickel mechanical properties close to carbon steel, its alkaline corrosion resistance in metal materials only second to silver, nickel wire in concentrated alkali surface will generate a layer of black protective film. Makes it very corrosion resistant. Used for electric light source materials, coating, with high surface quality, good processing performance, used for making work such as anode, partition, electrode bracket, etc., can also be used as a guide wire in the bulb, in addition to the chlor-alkali industry has played a very important role. Electrical grade materials because of the use of different conditions, and a variety of components of the alloy. Moreover, the electrode materials are required to have low resistivity to avoid overheating of the electrode, high high-temperature strength to reduce material wear, and sticky melting and volatilization to improve service life under the action of arc.
