Phosphor copper tube has a good deoxidizer, which can increase the fluidity of alloy, improve the process and mechanical properties of tin bronze. The limit solubility of phosphorus in tin bronze is 0.15%, too much will form a+δ+Cu3P terpolymer eutectic, melting point is 628℃, hot brittleness is easy to occur during hot rolling, only cold processing of phosphorus copper tube. Therefore, the phosphorus content in the deformed tin bronze should not be greater than 0.5%, and the phosphorus in the phosphorus copper tube should be less than 0.25% during hot working. Phosphor tin bronze is a famous elastic material. It is necessary to control the grain size before cold processing and low temperature annealing after processing. The strength, elastic modulus and fatigue strength of fine grain processed materials are higher than those of coarse-grain processed materials, but the plasticity is lower. The strength, plasticity, elastic limit, elastic modulus and elastic stability of cold working materials can be further improved by annealing and hardening effect at 200 ~ 260℃ for 1 ~ 2h. |
Item |
Phosphor Bronze Tube |
Size |
Outside Diameter: 3mm-330mm Size can be customized according to customer needs. |
Standard |
ASTM, AISI, JIS, ISO, EN, BS, GB, etc. |
Processing service |
Bending, Welding, Decoiling, Cutting, Punching, Customized |
Export to |
United States, Australia, Brazil, Canada, Germany, Peru, Japan, Italy, United Kingdom, Arabia, etc. |
Package |
waterproof paper,plastic bag, wooden case or as your requirements |
Price term |
EXW,FOB,CIF,CFR,CNF,etc. |
Payment |
T/T,Western Union,L/C,etc. |
Certificates |
TUV&ISO&GL&BV,etc. |
Cu (Min) |
90% |
Ultimate strength (≥ MPa) |
205 |
Application |
1) Heat exahanger tube for petrochemical,chemical and ocean development 2) Industrial furnace and heater tubes 3) For gas turbine and prochemical processing 4) Condenser tubes,sulfuric and phosphoric acids tubes,API tubing 5) Construction and ornament 6) Acid production,waste incineration,FGD,paper processing industrial etc |
