Zinc Alloy Tube

Name: Zinc-aluminum Alloy Tube
Brand: Qingdao StarGood Nonferrous Metal Co., Ltd.
SKU: 00459
Availability: InStock
Rating: 5 (1 reviews)

Home > Zinc > Zinc Alloy > Zinc Alloy Tube

Description

Zinc-aluminum alloy tube is a kind of high strength zinc-aluminum alloy tube, its composition and ratio are :Al,3.9 ~ 4.3%; Cu, 0.5 ~ 1.25%; Mg, 0.03 ~ 0.06%; Zinc, allowance. Zinc-aluminum alloy tube has excellent mechanical properties at room temperature and high temperature, especially excellent impact resistance, can resist the impact of large overload, good toughness. Zinc-aluminum alloy tube can be used to make low, medium speed, medium temperature heavy duty bearings or through continuous casting or centrifugal casting to make bearing bush, bushing profiles.

Item	Zinc-aluminum Alloy Tube
Size	OD: 26.9mm-310 mm or as required WT: 0.13 -- 3.0 mm or as required Length :1-12m or as required
Standard	ASTM, AISI, JIS, ISO, EN, BS, GB, etc.
Processing service	Bending, Welding, Decoiling, Cutting, Punching, Customized
Export to	United States, Australia, Brazil, Canada, Germany, Peru, Japan, Italy, United Kingdom, Arabia, etc.
Package	Kraft paper, carton, stretch film, non-woven fabric and crepe paper, plastic steel strip,customer requirements, etc.
Price term	EXW,FOB,CIF,CFR,CNF,etc.
Payment	T/T,Western Union,L/C,etc.
Certificates	TUV&ISO&GL&BV,etc.
Application	1).Heat exahanger tube for petrochemical,chemical and ocean development 2).Industrial furnace and heater tubes 3).for gas turbine and prochemical processing 4).Condenser tubes,sulfuric and phosphoric acids tubes,API tubing 5).Construction and ornament 6).Acid production,waste incineration,FGD,paper processing industrial etc

Preparation method:

After the zinc ingot and aluminum ingot are all melted, electrolytic copper is added in turn according to the composition ratio, and pressed into the zinc and aluminum liquid with graphite rod. The temperature is raised to 450℃, and the temperature is kept for 40 minutes to ensure that the copper is fully melted and evenly distributed. Magnesium metal is added according to the ratio, and the furnace is heated up to 580℃ ~ 650℃. Cast, extrude.
