Zirconium alloy sheet is an alloy plate composed of zirconium or other metals. Zirconium has a very low thermal neutron absorption cross section, ductility and corrosion resistance. The typical composition of nuclear grade zirconium alloy sheet is more than 95% zirconium and less than 2% tin, niobium, iron, chromium, nickel and other metals, the addition of these metals can be used to improve mechanical properties and corrosion resistance. |
Item |
Zirconium Alloy Sheet |
Standard |
ASTM, AISI, JIS, ISO, EN, BS, GB, etc. |
Surface treatment |
Polished, Pickled |
Size |
Thickness: 0.3mm~60mm Width: 30mm~1400mm Length: 500mm~7500mm Various sizes can be customized |
Process |
Vacuum consumable arc melting is the most common method for industrial production of zirconium alloys. Only by adding the correct alloying elements, the appropriate ratio of new and old materials and a reasonable casting system, can high-quality alloys be obtained. |
Export to |
United States, Australia, Brazil, Canada, Germany, Peru, Japan, Italy, United Kingdom, Arabia, etc. |
Transport package |
1.Carton with water proof paper and protective foam inside 2.Standard wooden case or carton cases 3.As consumers' requirements |
Price term |
EXW, FOB, CIF, CFR, CNF, etc. |
Payment |
T/T, Western Union, L/C, etc. |
Certificates |
TUV&ISO&GL&BV,etc. |
Tensile strength |
415MPa |
Yield strength |
240MPa |
Shape |
Sheet |
Elongation% |
14 |
Application |
Used to make plate heat exchangers, condensers, chemical and medical equipment, etc. |
R60704 chemical composition
Zr+Hf |
Hf |
Fe+Cr |
Sn |
C |
O |
N |
H |
≥97.5 |
≤4.5 |
0.2~0.4 |
1.0~2.0 |
≤0.05 |
≤0.18 |
≤0.025 |
≤0.005 |
